Detection Mode

Passive detection, does not actively emit radio signals in detection mode

Detection Frequency

300MHz~6GHz

Detection Angle

Horizontal 0°~360°, vertical -90°~90°

Detection Altitude

0～1200m

Detection Radius

5km（subject to variation depending on environment and drone model）

FPV analog video transmission signal detection

500MHz~6GHz scan and display

FPV analog video transmission signal detection distance

≥1.5km (support viewing real-time analog video)

Detection Time

≤5s

Detection Power Consumption

≤100W

Jamming Distance

3km（subject to variation depending on environment and drone model）

Jamming Angle Selection

Allows independent on/off control for multiple angles

Jamming Range

Horizontal: 360°; vertical: -90° to +90°.

Jamming Frequency Bands

900M/1.2GHz/1.5GHz/2.4GHz/5.2GHz/5.8GHz

Operating Frequency

Channel 1: (840±15) MHz to (930±15) MHz

Channel 2: (1535±15) MHz to (1635±15) MHz

Channel 3: (2380±15) MHz to (2520±15) MHz

Channel 4: (5130±15) MHz to (5370±15) MHz

Channel 5: (5725±15) MHz to (5885±15) MHz

Channel 6: (1080±15) MHz to (1200±15) MHz

Transmission Power

Channel 1: (47±1) dBm

Channel 2: (44±1) dBm

Channel 3: (47±1) dBm

Channel 4: (44±1) dBm

Channel 5: (47±1) dBm

Channel 6: (44±1) dBm

Jamming Response Time

≤3s

Suppression Distance Ratio

The maximum distance ratio between the system and the drone versus the drone and its controller should be no less than 15:1 in the absence of significant electromagnetic interference

Total Power Consumption

≤2300W

Mobile Power Supply

Mobile power supply; in full-frequency transmission mode, continuous operation for ≥30 minutes

Power Supply Mode

Supports 220V AC power or mobile power supply

High-Speed Operation

Capable of detecting and countering drones while in high-speed motion

Map Positioning

Equipped with an electronic map that can display the system’s geographic location in real-time

Alarm Function

Provides alarm notifications via information, sound, and light upon drone detection

Operating Temperature

（-20~+60）±2℃

Storage Temperature

（-60~+85）±2℃

Equipment Weight

64.25kg
