Frequency Range

400–500 MHz

Bandwidth range ±10 MHz

Frequency Range

500–600 MHz

Bandwidth range ±10 MHz

Frequency Range

700–840 MHz

Bandwidth range ±10 MHz

Frequency Range

840–960 MHz

Bandwidth range ±10 MHz

Frequency Range

950–1100 MHz

Bandwidth range ±10 MHz

Frequency Range

1100–1300 MHz

Bandwidth range ±10 MHz

Frequency Range

700–1050 MHz

Bandwidth range ±10 MHz

Working Voltage

32V

30–32V

Working Current

12–16A

Output 200W

Analog sweeping speed

120 kHz

8 μ/s

Output Power (Max)

53 ±1 dBm

200W

Gain (Max)

53 ±1 dB

—

Ripple in Band

≤ 3 dB

Peak

Bandwidth Adjustment

Yes

By screw

Center Adjustment

Yes

By screw

Enable Control

Customizable

30–32V

Input power (Max)

≤ +10 dBm

Optional (if signal source is user-provided)

Input Signal Source

Built-in high-speed noise-modulated signal source

Optional (customizable VCO, DDS, or SDR)

Output VSWR

≤1.5

Inside circulator, VSWR protect

High/Low Temperature Testing ‘

Working Temperature

-20～+65℃

Power supply Port

Gain Stability

±1 dB

Working properly

Power Stability

±1 dB

At

-20℃~+65℃

Positive and negative lines

30-32V;GND;

(optional: Enable control wire)

At

-20℃~+65℃

Shell Material

Aluminum with natural color oxide sand blasting

Vibration Need

Meet the load need of moving vehicle

RF output connector

N-Female

LED indicator light

Power ON/OFF

Dimension

150*80*22mm

Installation Dimension

144.3*74*22 mm

Screw Size

M2.5

Weight

800g
